Developed to meet the needs of modern industrial automation, the ALNWR.J combines precision, reliability, and continuous operation in a compact and ergonomic design. Paired with the RDC EVO radio receiver, it features 2-axis Hall-effect joysticks, bidirectional radio communication, and a rugged construction, providing intuitive machine control and outstanding performance even in the harshest industrial environments.

Precise control with 2-Axis Hall-effect joysticks

At the heart of the ALNWR.J are miniaturized 2-axis Hall-effect joysticks, designed without mechanical contacts subject to wear. This technology ensures:

• High control precision

• Long service life (over 5 million cycles)

• Automatic spring return to center

• Low operating force (1.5 N ±0.5 N)

Hall-effect technology also provides consistent performance over time while minimizing maintenance requirements.

Ergonomic design and maximum visibility

The front panel features 10 backlit pushbuttons, complemented by 16 programmable spotlight LEDs, ensuring excellent visibility even in low-light working conditions.

The user interface also includes:

• Programmable bi-color status LEDs

• Battery level indicator

• Dedicated charging status LED

• Emergency stop button with visual feedback

• Rubber grip for secure handling

• Low-profile guard to prevent accidental operation

In addition, the keypad graphics, pictograms, and company logo can be fully customized to meet specific application requirements.

Reliable radio communication

The ALNWR.J communicates with the RDC EVO receiver via a bidirectional radio link operating on the 434 MHz or 868 MHz frequency bands.

Key communication features include:

• Automatic channel scanning

• Integrated antenna

• Operating range of up to 100 meters (under typical laboratory conditions)

• Hamming security code, ensuring uninterrupted operation while minimizing the risk of interference

These features make the system ideal for applications where operational continuity and safety are critical.

Smart battery management and fast charging

The remote control is equipped with an integrated 3.7 V – 1200 mAh Li-Ion battery, which can be fully recharged in less than two hours via a USB Type-C connector, compatible with standard USB chargers.

An additional advantage is the predictive maintenance function, which continuously monitors battery health and helps identify potential maintenance needs before they become critical, reducing downtime and improving operational continuity.

Designed for industrial environments

The ALNWR.J is engineered to operate reliably under demanding industrial conditions, offering:

• IP63 protection rating

• Operating temperature from -20°C to +60°C

• CE (RED) and UKCA certifications

• Compliance with major European standards for safety, electromagnetic compatibility, and radio communications

The system is also designed for seamless integration with the RDC EVO receiver, which supports high-safety architectures and is compatible with SIL2 and PLd standards.

A complete solution for remote machine control

Combining a compact design, high-precision Hall-effect joysticks, secure radio communication, fast charging, and advanced battery diagnostics, the ALNWR.J provides a reliable solution for the remote control of industrial machinery.

Designed to work seamlessly with the RDC EVO system, it delivers the ideal combination of precise control, operational safety, and maximum uptime, meeting the demands of today's most advanced industrial applications.
